Orginal: China
Driving system: Motor, diesel engine, diesel generator support
Capacity: 1-1000Ton/h per set
Power：1.5 kw -100 kw per set
Types: Mobile, fixed etc
Used to: Wash, screen and separate in one. All kinds of stone , sand , soil, mining , gold mining, topsoil,compost, coal etc.
Gold washing processing plant includes : Washing process, screening process, gravity separation process, beneficiation process
1.Washing process:
Main machine:
Cylindrical washing machine, trough washing machine, shaftless drum screen, vibrating screen
Main step:
An important process preceding gold ore separation, as placer gold deposits contain significant amounts of weathered clay, within which the gold is embedded. The purpose of the washing process is to separate gravel, sandy soil, and silt, while cleaning fine mud adhering to gravel and separating gold-bearing sand intermixed within it. Washing operations employ water flushing and mechanical agitation—such as flat vibrating screens, drum washers, and drum screens—to liberate mineral sands trapped within cemented lumps or muddy masses.
2.screening process
Main steps:
The main purpose is to screen the washed sand gold ore and remove large non gold bearing gravel to improve the gold selection efficiency. Screening operations can remove 20-40% of waste rocks, and water screening is often used. Screen and wash water to break up scattered mineral mud to improve screening efficiency.
3.Gravity separation:
Main machine:
Wet shaking table, centrifugal Mineral Separator, screw separator , jigging machine
Main step:
An important process preceding gold ore separation, as placer gold deposits contain significant amounts of weathered clay, within which the gold is embedded. The purpose of the washing process is to separate gravel, sandy soil, and silt, while cleaning fine mud adhering to gravel and separating gold-bearing sand intermixed within it. Washing operations employ water flushing and mechanical agitation—such as flat vibrating screens, drum washers, and drum screens—to liberate mineral sands trapped within cemented lumps or muddy masses.
4.Beneficiation process:
Main machine:
Gemini shaker table
Main step:
The selective processing stage is an indispensable step in the gold ore beneficiation process, significantly enhancing the recovery efficiency of gold and other heavy minerals to achieve comprehensive recovery. Depending on the specific type of gold ore, selective processing may employ various equipment and methods such as gravity separation equipment or amalgamation equipment, with the objective of further increasing the gold content.
